Empower modern construction with structural bracing Plywood

Empower modern construction with structural bracing Plywood

Short Description:

With its F22 strength grade, SENSO Structural Bracing Plywood is engineered to withstand various natural forces, including earthquakes and high winds. It offers exceptional structural integrity and reliability, giving you the confidence that your building can withstand challenging environmental conditions.

SENSO Structural Bracing Plywood has been extensively tested and used in the Australian environment for over 10 years. It meets the strength grade requirements outlined in the Australian Standard, ensuring it meets the highest quality and performance standards.



Product Detail

Normal

Thickness

Sheet Size (mm)

Grade

Density   (kg/cm)







Glue

Thickness

tolerance

Packing

Unit

(sheets)

Face and back

Core Materials

Moisture







4.0mm

2400×900

F22

650

Hardwood

Hardwood

8-14 %

A bond

Super E0

+/-0.2mm

100 / 400

4.0mm

2400×1200

650

Hardwood

Hardwood

8-14 %

+/-0.2mm

100 / 400

4.0mm

2745×900

650

Hardwood

Hardwood

8-14 %

+/-0.2mm

100 / 400

4.0mm

2745×1200

650

Hardwood

Hardwood

8-14 %

+/-0.2mm

100 / 400

4.0mm

3050×900

650

Hardwood

Hardwood

8-14 %

+/-0.2mm

100 / 400

4.0mm

3050×1200

650

Hardwood

Hardwood

8-14 %

+/-0.2mm

100 / 400

Uses and Applications of 2400 x 900mm 4mm Structural Bracing Plywood

  • Seismic Resistance: Earthquakes can exert powerful lateral forces on buildings, leading to potential collapse if not adequately addressed. Structural bracing plywood plays a pivotal role in seismic design by distributing these forces and minimizing their impact. Buildings in seismic-prone regions often incorporate bracing plywood to enhance their resilience.
  • Wind Load Mitigation: High winds are another natural force that can stress buildings laterally.2400 x 900mm 4mm Structural Bracing Plywood, strategically placed within walls, roofs, and floors, helps absorb and redirect wind loads, preventing structural failure.
  • Tall Buildings and Towers: Tall structures are susceptible to swaying due to wind or external forces. Structural bracing plywood, when employed thoughtfully, helps mitigate this sway, ensuring occupant comfort and structural integrity.
  • Industrial and Commercial Spaces: Large open spaces in warehouses, factories, and commercial structures can benefit from bracing plywood to counteract vibrations caused by heavy machinery or equipment, maintaining the building’s stability over time.

Benefits:

  • Strength & Resilience: Engineered for exceptional sturdiness, it withstands lateral forces while upholding integrity.
  • Effortless Integration: Seamlessly fits into various components, minimizing design adaptations.
  • Economical Longevity: Initial investment pays dividends through prolonged lifespan and diminished maintenance.
  • Augmented Security: Enhances safety during seismic events and potent winds.
  • Sustainable: Environmentally conscious due to responsible wood sourcing and reduced replacements.
  • Time-Economizing: Simplified installation expedites project completion
SENSO 4mm Structural Bracing Plywood Packing and Loading

Container Type

Pallets

Volume

Gross Weight

Net Weight

20 GP

10 pallets

20 CBM

13000KGS

12500KGS

40 HQ

20 pallets

40 CBM

25000KGS

24500KGS

https://www.plywood.cn

SENSO 4mm Structural Plywood Certified By

CERTMARK JASFSCIALCNASDNV

Meanwhile, we also can supply you the formwork system accessories, commercial plywood, film-faced plywood, etc.

We are especially professional in supplying antislip plywood.
Please contact our sales team for more detailed information regarding Chinese plywood.

SENSO Structural Plywood
www.plywood.cn
